La definición de arado de disco.

The disc plow is a cultivating machine and it is towed by a tractor. The vertical disc plough products are mainly used for plowing the cultivated land in dry farming areas, especially suitable for plowing high-yield green manure fields and returning rice and wheat stubble to the field.

Diferentes tipos de arados de discos

Tipo uno: arado de un solo disco

The single-disc plow is towed by a tractor. When working, the unit advances, the disc rolls and cuts into the soil, and the soil rises along the concave surface of the disc. At the same time, with the cooperation of the scraper, the soil is turned and broken.

We have seven different models of this one-way disc plow. The first three types of tillage widths are different, but the tillage depth is 200 mm, and the latter four models are all 250 to 300 mm deep. When the matching horsepower is 18, we will use a pequeño motocultor. Note that different tractors must be used to tow different disc plows.

La estructura del arado de un solo disco.

Look at the picture, our single disc plow consists of the following parts: upright, plow frame welding, tie rod welding, lower suspension pin, fillet welding, front plough post welding, and plough disk. Different types of single disc ploughs should be driven by different tractors.

Technical parameters of our machine

Type Two: Circular tube disc plough

The circular tube disc plow is matched with the tractor’s full suspension link, and the plow blade rotates during operation to plow and turn the soil. It has the characteristics of not tangling grass, not constricting the soil, not blocking, being able to cut off crop stalks and rhizomes, and having less working resistance.

We have four different models of circular tube disc plows. The tillage is different, and the tillage depth is 250 to 300 mm. Due to the different horsepower, tractors of different horsepower are used to tow.

Structure of circular tube plough

The circular tube disc plow is mainly composed of these parts: tailwheel, heavy suspension, and plow blade.

Parámetro técnico del arado de disco de tubo circular

Tipo tres: arado de disco 1LY

1LY disc plow refers to the characteristics of foreign disc plows and creates designs based on them. The 1LY series disc plow is mainly used for plowing operations in dryland or raw land. It has the characteristics of low resistance and simple operation.

The 1LY series disc plow includes four different models. The farming widths of adjacent models are different by 300 mm, the tillage depth is the same, and tractors with different horsepower are required to pull.

La estructura del arado de disco 1LY.

The 1LY disc plough is composed of three main parts: frame, linkage point, and plow disc. Other pictures are a detailed introduction to the parts.

Parámetro técnico del arado de disco 1LY

Application of our machine

Our disc plows are of extremely high quality and efficiency and are suitable for dry land and paddy fields. Before planting rice, plowing the land is good for the growth of rice. When plowing in the paddy field, it can completely turn the soil and level it.

It can cut wheat and rice straws and bury them in the soil. They rot in the soil and increase the organic matter of the soil. The disc plow is connected with the full suspension of the tractor.

During operation, the plow blade rotates to the plow and turns the soil. It is especially suitable for overgrown weeds, the stems are upright, the specific resistance of the soil is large, and there are complex masonry pieces in the soil.

Cómo mantener el arado de discos.

• Verifique exhaustivamente el aspecto de la máquina, repinte la pintura y aplique aceite al machete y al eje estriado para evitar la oxidación.
• Compruebe si falta aceite en la caja de transmisión, los diez bytes y los cojinetes y rellénelo inmediatamente si es necesario.
• Verifique y apriete los pernos de conexión.
• Compruebe si las piezas vulnerables, como pernos y pasadores, están dañadas y reemplácelas si es necesario.
• Retire completamente el barro, el polvo y el aceite del equipo.
• Reemplace completamente el aceite lubricante y la grasa.

Tractor con arado de discos

As mentioned above, we have many types of disc plow, 3 disc plow, 4 disc plow, 5 disc plow, 6 disc plow, etc. Therefore, different disc plow requires tractors with different horsepower. Small disc plows can use 18-horsepower walking tractors, and large disc plows can use medium or large tractors. Under the tractor’s traction, the disc plow can work very well, and the work efficiency is very high.

¿Por qué usamos arado?

Land is an important guarantee for people’s lives. In the past, people used labor or livestock to plow the land, but this is a waste of the labor force and it is inefficient. The vertical disc plow can effectively solve this problem and make the soil more fertile.

Fertile land can better grow crops and make people get higher yields. In the plowed land, the soil gap is enlarged and the air permeability is good. Water and air can enter the soil well and can be well retained. Plowing can make the soil soft and suitable for the growth of crop roots and nutrient absorption.

The temperature during spring plowing is still relatively low, and plowing can kill some of the pests hidden in the soil for overwintering, which can reduce the damage to seeds by the pests. Therefore, the plow is very important for farmers.

¿Cuál es el precio del equipo?

Según la tabla de parámetros anterior, podemos ver que el número de hojas de arado de disco de diferentes modelos es diferente, y la profundidad y el ancho de labranza son diferentes. Por lo tanto, el precio de cada arado de discos no es fijo, usted puede elegir el arado de discos adecuado según sus necesidades y nuestro gerente comercial le dará una cotización precisa.

Disc plough in the Philippines

Este es un video de comentarios de nuestros clientes filipinos. Él cree que con la tracción del tractor correspondiente, nuestro arado de discos tiene una gran intensidad de trabajo y puede remover el suelo profundo. El arado de discos es arrastrado por un tractor, lo que hace que la conducción sea extremadamente estable y segura, sin turbulencias y no provoca mareos.

Nuestra fábrica y productos.

Our company specializes in agricultural machinery products, established for many years. Our factory has strong strength and sufficient inventory, so please don’t worry about out-of-stock issues. Our products are made of upper-level materials, and the production process is checked several times, so the quality is guaranteed.

If you are interested in our products, please leave your contact information, and our co-workers will contact you within 24 hours. We hereby promise that we will give you the most intimate service, the most favorable price, and the best product quality. Welcome to contact us.
