4 types of automatic corn sheller for sale / shelling corn maize

corn shelling / maize threshing / corn thresher

Hot sale corn sheller in our company, TY-80A, TY-80B, TY-80C, TY-80D, all are equipped with high capacity, that is, 4-6t/h. Corn thresher machine is mainly composed of feeding hopper, internal threshing and rolling device,air separation system including elevator, fan and chaff absorber, vibrating cleaning screen, frame, transmission system etc. Corn threshed by this machine is very clean without impurities such as crushed corn cobs and corn rinds.

Technical parameter of corn sheller

ModeTY-80ATY-80BTY-80CTY-80D
Power15HP diesel engine or 7.5 KW motor15HP diesel engine or 7.5 KW motor15HP diesel engine or 7.5 KW motor15HP diesel engine or 7.5 KW motor
Capacity4t/h (Corn seeds )5t/h (Corn seeds )5t/h (Corn seeds )6t/h (Corn seeds )
Threshing rate≥99.5% ≥99.5%≥99.5%≥99.5%
Loss rate≤2.0%≤2.0%≤2.0%≤2.0%
Breakage rate≤1.5%≤1.5%≤1.5%≤1.5%
Impurity rate≤1.0%≤1.0%≤1.0%≤1.0%
Weight200kg230kg320kg350kg
Size2360*1360*1480 mm2360*1360*2000 mm3860*1360*1480 mm3860*1360*2480 mm

                                  TY-80A                                                          TY-80B

                              TY-80C                                                           TY-80D



Advantage of corn sheller

  1. High threshing rate and low impurities. The former is more than 99.5% and the latter is less than 1%.
  2. High capacity. Its capacity, 4-6t/h, is higher than the machines in most markets.
  3. Automatical feeding hopper is able to convey corns quickly, which can greatly save time and energy.
  4. Threshing chamber can fully separate seeds from corn cobs.
  5. Cleaning rate so high that you can not find any impurities in the corn kernels.

Working principle of corn sheller

  1. Users place the corn into automatic feeding conveyor.
  2. Then corns are conveyed into threshing chamber.
  3. After threshing and separating by rollers, corn seeds and a small number of impurities go into the stirrer from the concave board and then to the sieve by elevator.
  4. Impurities that are smaller than corn drop off from the screen, and corn seeds and other major bigger impurities move along with the screen until outlet.
  5. After several seconds, small impurities are discharged out by absorber, corn seeds go into the bag from sieve.
  6. The corn cobs without kernels are discharged from the straw outlet.

Successful case of corn sheller

Last month, we sold 20 sets maize thresher machine to Congo, and the followings are the delivery pictures.



FAQ of corn sheller

  1. What is the difference of 4 types of corn sheller for sale ?

Automatical feeding inlet and long lifter can improve the working efficiency, so 4 types of corn sheller machines bear different capacities.

  1. What are their capacities?

TY-80A:4t/h

TY-80B:5t/h

TY-80C:5t/h

TY-80D: 6t/h

  1. Why are corn cobs are too fragile?

Corn cobs may be rotten or the discharge hole of it is rather slow.

  1. Why are there so many impurities?

Removing one or two discharging parts can improve threshing rate.

  1. Can the slope of vibrating screen be adjustable?

Yes, you can adjust the height of two supporting frames.
